SONIC 3500

SONIC 3500, is a hydraulic drill, with top hammer system, designed for high production, and high reach with security. Attached to a excavator, ready for drilling and blasting contractors, quarries, rock bolting, rock stabilization. The operator controls the rig inside the cab, avoiding risks of accident. In few minutes, with a unique equipment, we have: drilling, demolition and excavation.

p_02-01-13_foto_sonic_3500
p_02-49-25_foto_site_2
p_02-56-42_foto_4
p_02-56-43_foto_3
p_04-18-38_Horical_2
p_12-24-20_Excavatriz_2
p_12-24-20_Excavatriz_3
p_12-24-20_Excavatriz_4
p_12-24-21_Excavatriz_6
p_12-24-22_Excavatriz_7
p_12-24-22_Excavatriz_8
p_12-24-23_Comandos_da_Cabina
p_12-24-23_Martelo
p_12-24-24_Esticador
p_12-24-24_Inclinometro
p_12-24-24_Trocador_de_hastes
p_12-24-25_Bomba_de_graxa

Video

Download the PDF

Drilling details:

* Rod type:  T38MF / T45MF

* Hole depth:  25m (82′)

* Drilling diameter:  2.1/2″ – 4″ (64 – 102mm)

* Rod length:  3,6m (12″)

* Feed force:  20 kN (4500 lbf)

Rod changer:

* Number of rods:  6 + 1

* Type:  Carrosel

Drifter W-19 (Top Hammer):

* Impact power:  19kw / 26hp

* Work pressure:  2030 PSI / 140 bar

* Rotation torque:  750 Nm

* Rotation speed:  0 – 150 rpm

* Weigth:  237 kg

  • Hydraulic Centralizer;

  • Rod’s Greaser;

  • Grease Pump;

  • Auto Rod Changer;

  • Slide Hood;

  • Hose Reel;

  • Controls on Board;

  • Dust Collector (primary / secundary);

  • Hydraulic Drifter;
    • Radio control.

    • Water Tank;

    • Digital Angle Inclinometer;

    • Anti Jamming;

    • Pneumatic Compressor Frame;

    • Air Shut-off System;

    • Hydraulic Driven Compressor;

    • Nitrogen Charger (cylinder not included).

  • The excavator must have an auxiliar hydraulica kit, start button for auxiliar output of excavator ON-OFF and output for control panel connection of 12 volts;

+
Technical Features

Drilling details:

* Rod type:  T38MF / T45MF

* Hole depth:  25m (82′)

* Drilling diameter:  2.1/2″ – 4″ (64 – 102mm)

* Rod length:  3,6m (12″)

* Feed force:  20 kN (4500 lbf)

Rod changer:

* Number of rods:  6 + 1

* Type:  Carrosel

Drifter W-19 (Top Hammer):

* Impact power:  19kw / 26hp

* Work pressure:  2030 PSI / 140 bar

* Rotation torque:  750 Nm

* Rotation speed:  0 – 150 rpm

* Weigth:  237 kg

+
Available Items

  • Hydraulic Centralizer;

  • Rod’s Greaser;

  • Grease Pump;

  • Auto Rod Changer;

  • Slide Hood;

  • Hose Reel;

  • Controls on Board;

  • Dust Collector (primary / secundary);

  • Hydraulic Drifter;
    • Radio control.
+
Optionals

    • Water Tank;

    • Digital Angle Inclinometer;

    • Anti Jamming;

    • Pneumatic Compressor Frame;

    • Air Shut-off System;

    • Hydraulic Driven Compressor;

    • Nitrogen Charger (cylinder not included).

+
Excavator requirements

  • The excavator must have an auxiliar hydraulica kit, start button for auxiliar output of excavator ON-OFF and output for control panel connection of 12 volts;
