FOX 8-20

Hydraulic Crawler Drill

The Hydraulic Crawler Drill FOX 8-20 is an excellent option for rock drilling equipment, that can be applied in Quarries, Open Cast Mining and Drilling Service Contractors. This equipment guarantees high productivity with low maintenance cost, and 100% Brazilian technology.

p_04-06-45_Foto_Banner_e_Principal
Slide background
p_04-06-46_Foto_1
p_04-06-46_Foto_2
p_04-06-46_Foto_3
p_04-06-46_Foto_4
p_04-06-47_Foto_5
p_04-06-47_Foto_6

Video

* Diesel engine 4cc TIER 3 – UNIQUE IN THE CLASS;

* Equipment with low diesel consumption – average 14 l/h (3,7 gal);

* High performance – average 33 linear metres hour;

* Easy operation and simple maintenance;

* Compact equipment – SMALLER IN ITS CLASS;

* Easy and fast displacement;

* Damp suppressor according to Regulatory Mining Standard NRM 9.

Hole range:

* Rod type: T38MF / T45MF

* Hole depth: 25m (82′)

* Drilling diameter: 2.1/2″ – 3.1/2″ (64mm – 89mm)

* Rod length: 3,6m (12′)

* Feed force: 20 kN (4.500 lbf)



Diesel engine:

* Brand: Cummins

* Model: QSB 4cc – TIER 3

* Power: 130 hp

* Cooling: Water

* Tank capacity: 285 lt (62,9 gal)



Compressor unit:

* Compressor type: Screw

* Working pressure: 105 psi (7 bar)

* FAD: 180 pcm / cfm (5 m3/min)



Tramming features:

* Tramming speed (low): 0 – 25 km/h (0 – 3,75 mph)

* Tramming speed (high): 0 -4,5 km/h (0 – 6,75 mph)

* Traction force: 7.700 N.m

* Track gradient: 47%

* Track frame oscillation: 9º



Rod Changer:

* Number of rods: 6 + 1

* Type:  Carousel



Drifter MW80H (Top Hammer):

* Working pressure: 120 bar (2.030 psi)

* Rotation torque: 750 Nm (553 lbf/ft)

* Rotation speed: 0 – 150 rpm

* Weight: 237 kg



Dimensions:

* Weight: 8.500 kg

* Width: 2.321 mm

* Length: 7.300 mm

* Height: 3.700mm

* Hydraulic centralizer;

* Automatic greaser;

* Auto rod relay;

* Digital angle inclinometer;

* Water tank;

* Nitrogen charger (cylinder not included);

* Spotlights

* Dust Collector (primarily and secondarily)

+
Advantages

* Diesel engine 4cc TIER 3 – UNIQUE IN THE CLASS;

* Equipment with low diesel consumption – average 14 l/h (3,7 gal);

* High performance – average 33 linear metres hour;

* Easy operation and simple maintenance;

* Compact equipment – SMALLER IN ITS CLASS;

* Easy and fast displacement;

* Damp suppressor according to Regulatory Mining Standard NRM 9.

+
Technical Features

Hole range:

* Rod type: T38MF / T45MF

* Hole depth: 25m (82′)

* Drilling diameter: 2.1/2″ – 3.1/2″ (64mm – 89mm)

* Rod length: 3,6m (12′)

* Feed force: 20 kN (4.500 lbf)



Diesel engine:

* Brand: Cummins

* Model: QSB 4cc – TIER 3

* Power: 130 hp

* Cooling: Water

* Tank capacity: 285 lt (62,9 gal)



Compressor unit:

* Compressor type: Screw

* Working pressure: 105 psi (7 bar)

* FAD: 180 pcm / cfm (5 m3/min)



Tramming features:

* Tramming speed (low): 0 – 25 km/h (0 – 3,75 mph)

* Tramming speed (high): 0 -4,5 km/h (0 – 6,75 mph)

* Traction force: 7.700 N.m

* Track gradient: 47%

* Track frame oscillation: 9º



Rod Changer:

* Number of rods: 6 + 1

* Type:  Carousel



Drifter MW80H (Top Hammer):

* Working pressure: 120 bar (2.030 psi)

* Rotation torque: 750 Nm (553 lbf/ft)

* Rotation speed: 0 – 150 rpm

* Weight: 237 kg



Dimensions:

* Weight: 8.500 kg

* Width: 2.321 mm

* Length: 7.300 mm

* Height: 3.700mm

+
Available Items

* Hydraulic centralizer;

* Automatic greaser;

* Auto rod relay;

* Digital angle inclinometer;

* Water tank;

+
Optionals

* Nitrogen charger (cylinder not included);

* Spotlights

* Dust Collector (primarily and secondarily)
