FOX 12-30

Hydraulic Crawler Drill

The Hydraulic Crawler Drill FOX 12-30 is an excellent option for rock drilling equipment, that can be applied in Quarries, Open Cast Mining and Drilling Service Contractors. This equipment guarantee high productivity with low maintenance cost, and 100% of brazilian technology.

p_10-13-06_Fox_8
Slide background
p_08-16-52_Coletor_de_Po_1
p_08-16-52_Avanco
p_08-16-51_Cabine_2
p_08-16-50_Lateral_direita
p_08-16-52_Vista_da_cabina
p_08-16-53_Coletor_2
p_08-16-52_Boom
p_08-16-53_Traseira
p_08-16-54_Qualidade_na_furacao
p_10-13-05_Fox_5
p_10-13-05_Fox_6
p_10-13-06_Fox_7
p_10-13-06_Fox_9
p_10-18-55_Trocador
p_12-43-17_Fox_10
p_12-43-18_Fox_11
p_12-43-18_Fox_12
p_12-51-39_foto_nova_5

Video

Download the PDF

Drilling details:

* Rod type:  T38MF / T45MF

* Hole depth:  25m (82′)

* Drilling diameter:  2.1/2″ – 4″ (64 – 102mm)

* Rod length:  3,6m (12″)

* Feed force:  29 kN (4500 lbf)



Diesel engine:

* Brand:  Cummins

* Model:  6CTA-8.3

* Power:  1800 rpm – 214 hp (158 kw)

* Refrigeration: Water

* Tank capacity:  285 lt (62,9 gal)



Compressor unit:

* Compressor type:  Screw

* Work pressure:  116 PSI (8 bar)

* FAD:  250 PCM / CFM (7m3/min)



Tramming features:

* Tramming speed (low):  0 – 2,5 km/h (0 – 3,75 mph)

* Tramming speed (high):  0 – 4,5 km/h (0 – 6,75 mph)

* Traction force:  7700 n.m@220 bar

* Track inclination:  47%

* Track oscillation:  +/- 18º



Rod charger:

* Number of rods:  6 + 1

* Type:  Carousel



Drifter W-19 (Top Hammer):

* Impact power:  19kw / 26hp

* Work pressure:  2030 PSI / 140 bar

* Rotation torque:  750 Nm

* Rotation speed:  0 – 150 rpm

* Weigth:  237 kg



Dimensions:

* Weigth:  13000kg

* Width:  2500mm

* Length:  10500mm

* Heigth:  3600mm

  • Hydraulic Centralizer;

  • Rod Greaser;

  • Rod Changer;

  • Digital Angle Inclinometer (Mast);

  • Engine’s Cover;

  • Rose Heel

  • Night Lights;

  • Anti Jamming

  • Rear Siren;

  • Horn;

  • Extension Boom;

  • Dust Collector (primary / secundary);

  • Cabin;

  • Air Conditioning;

  • Water Mist System (capacity of 150 l / 40 gal);

  • Mechanical Angle Inclinometer (Chassis)

  • Lifting Eye

  • Nitrogen Charger (nitrogen cylinder is not included);

  • Qulaity Control in Drilling Operation.



+
Technical Features

Drilling details:

* Rod type:  T38MF / T45MF

* Hole depth:  25m (82′)

* Drilling diameter:  2.1/2″ – 4″ (64 – 102mm)

* Rod length:  3,6m (12″)

* Feed force:  29 kN (4500 lbf)



Diesel engine:

* Brand:  Cummins

* Model:  6CTA-8.3

* Power:  1800 rpm – 214 hp (158 kw)

* Refrigeration: Water

* Tank capacity:  285 lt (62,9 gal)



Compressor unit:

* Compressor type:  Screw

* Work pressure:  116 PSI (8 bar)

* FAD:  250 PCM / CFM (7m3/min)



Tramming features:

* Tramming speed (low):  0 – 2,5 km/h (0 – 3,75 mph)

* Tramming speed (high):  0 – 4,5 km/h (0 – 6,75 mph)

* Traction force:  7700 n.m@220 bar

* Track inclination:  47%

* Track oscillation:  +/- 18º



Rod charger:

* Number of rods:  6 + 1

* Type:  Carousel



Drifter W-19 (Top Hammer):

* Impact power:  19kw / 26hp

* Work pressure:  2030 PSI / 140 bar

* Rotation torque:  750 Nm

* Rotation speed:  0 – 150 rpm

* Weigth:  237 kg



Dimensions:

* Weigth:  13000kg

* Width:  2500mm

* Length:  10500mm

* Heigth:  3600mm

+
Available Items
  • Hydraulic Centralizer;

  • Rod Greaser;

  • Rod Changer;

  • Digital Angle Inclinometer (Mast);

  • Engine’s Cover;

  • Rose Heel

  • Night Lights;

  • Anti Jamming

  • Rear Siren;

  • Horn;

  • Extension Boom;

  • Dust Collector (primary / secundary);

  • Cabin;

  • Air Conditioning;

+
Optionals

  • Water Mist System (capacity of 150 l / 40 gal);

  • Mechanical Angle Inclinometer (Chassis)

  • Lifting Eye

  • Nitrogen Charger (nitrogen cylinder is not included);

  • Qulaity Control in Drilling Operation.
