FOX 12-20

Hydraulic Crawler Drill

The Hydraulic Crawler Drill FOX 12-20 is an excellent option for rock drilling equipment, that can be applied in Quarries, Open Cast Mining and Drilling Service Contractors. This equipment guarantee high productivity with low maintenance cost, and 100% of brazilian technology.

p_10-16-38_Foto_site_3
p_10-16-38_Foto_site_4
p_12-38-19_Foto_3
p_09-21-05_Esticador
p_09-21-06_Painel_2
p_09-21-05_Redutor
p_09-21-05_Martelo
p_09-21-04_Centralizador
p_09-21-03_Coletor_de_po_1
p_09-21-03_Coletro_de_po_2
p_09-21-04_Bomba_de_graxa
p_09-21-06_Painel_1
p_10-16-38_Foto_site_1
p_10-16-38_Foto_site_5

Video

Hole range:

* Rod type:  T38MF / T45MF

* Hole depth:  25m (82′)

* Drilling diameter:  2.1/2″ – 4″ (64 – 102mm)

* Rod length:  3,6m (12″)

* Feed force:  20 kN (4500 lbf)



Diesel engine:

* Brand:  Cummins

* Model:  6CTA-8.3

* Power:  1800 rpm – 214 hp (156kw)

* Refrigeration:  Water

* Tank capacity:  285 lt (62,9 gal)



Compressor unit:

* Compressor pressure:  Screw

* Work pressure:  116 PSI (8 bar)

* FAD:  250pcm / cfm (7m3/min)



Tramming features:

* Tramming speed (low):  0 – 2,5 km/h (0 – 3,75 mph)

* Tramming speed (high):  0 – 4,5 km/h (0 – 6,75 mph)

* Traction force:  7700 N.m@220bar

* Track inclination:  47%

* Track oscillation:  +/- 18º



Rod changer:

* Number of rods:  6 + 1

* Type:  Carrosel



Drifter MW-80H:

* Impact power:  19 kw / 26 hp

* Work pressure:  2030 PSI / 140 bar

* Rotation torque:  750 Nm

* Rotatio speed:  0 – 150 rpm

* Weigth:  237kg



Dimensions:

* Weight:  12000kg

* Width:  2500mm

* Length:  10500mm

* Height:  3600mm

Hydraulic Centralizer;

Automatic Greaser;

Auto Rod Relay;

Mechanic Angle Inclinometer;

Engine’s cover;

Spotlights;

Rear Siren;

Horn;

Dust Collector (primary / secundary);

Water Tank;

Mechanic Angle Inclinometer;

  • Anti Jamming;

  • Extension Boom

  • Nitrogen Charger;
  • Quality Control in Drilling Operation.

+
Technical Features

Hole range:

* Rod type:  T38MF / T45MF

* Hole depth:  25m (82′)

* Drilling diameter:  2.1/2″ – 4″ (64 – 102mm)

* Rod length:  3,6m (12″)

* Feed force:  20 kN (4500 lbf)



Diesel engine:

* Brand:  Cummins

* Model:  6CTA-8.3

* Power:  1800 rpm – 214 hp (156kw)

* Refrigeration:  Water

* Tank capacity:  285 lt (62,9 gal)



Compressor unit:

* Compressor pressure:  Screw

* Work pressure:  116 PSI (8 bar)

* FAD:  250pcm / cfm (7m3/min)



Tramming features:

* Tramming speed (low):  0 – 2,5 km/h (0 – 3,75 mph)

* Tramming speed (high):  0 – 4,5 km/h (0 – 6,75 mph)

* Traction force:  7700 N.m@220bar

* Track inclination:  47%

* Track oscillation:  +/- 18º



Rod changer:

* Number of rods:  6 + 1

* Type:  Carrosel



Drifter MW-80H:

* Impact power:  19 kw / 26 hp

* Work pressure:  2030 PSI / 140 bar

* Rotation torque:  750 Nm

* Rotatio speed:  0 – 150 rpm

* Weigth:  237kg



Dimensions:

* Weight:  12000kg

* Width:  2500mm

* Length:  10500mm

* Height:  3600mm

+
Available Items

Hydraulic Centralizer;

Automatic Greaser;

Auto Rod Relay;

Mechanic Angle Inclinometer;

Engine’s cover;

Spotlights;

Rear Siren;

Horn;

Dust Collector (primary / secundary);

+
Optionals

Water Tank;

Mechanic Angle Inclinometer;

  • Anti Jamming;

  • Extension Boom

  • Nitrogen Charger;
  • Quality Control in Drilling Operation.
